Here are the specifications for the dbx DriveRack VENU360:

Audio Specifications
- *Inputs:*
   - 3 analog line inputs/2 AES digital inputs (shared connectors)
   - 1 RTA mic input
   - Input Connectors: 3 female XLRs (2 selectable between analog/AES digital audio formats), 1 female XLR RTA mic input
- *Input Type:* Electronically balanced/RF filtered
- *Input Impedance:* > 30 kΩ, balanced line to line
- *Max Input Level (line inputs):* > +28 dBu, balanced, ≤1% THD
- *CMRR:* > 50 dB @ 1 kHz

Output Specifications
- *Outputs:* 6 line outputs
- *Output Connectors:* Male XLR
- *Output Type:* Electronically balanced, RF filtered
- *Output Impedance:* 120 Ω, balanced line to line
- *Max Output Level:* +22 dBu, balanced, ≤1% THD

Processing Specifications
- *A/D Converter:* 24-bit with dbx Type IV Conversion System
- *D/A Converter:* 24-bit
- *Internal Processing Wordlength:* 32-bit floating point
- *Supported Sample Rates:* 48/96 kHz (32-192 kHz using sample rate conversion)

Performance Specifications
- *Dynamic Range:* 114 dB A-weighted; 110 dB unweighted
- *THD+Noise:* 0.0025% typical at +4 dBu, 1 kHz, 0 dB input gain
- *Frequency Response:* 20 Hz – 20 kHz, +0 /- 0.5 dB
- *Latency:*
   - Analog input to output: 2.57 ms (48 kHz), 2.28 ms (96 kHz)
   - Digital AES input to output: 2.31 ms (48 kHz), 2.15 ms (96 kHz)

Physical Specifications
- *Dimensions:* 1.75” (H) x 8.0” (D) x 19” (W) (4.4cm x 20.32cm x 48.26cm)
- *Unit Weight:* 5.48 lbs. (2.49 kg)
- *Shipping Weight:* 7.10 lbs. (3.22 kg)
- *Operating Voltage:* 100-240 VAC 50/60 Hz
- *Power Consumption:* 18 W ¹
