The dbx DriveRack 260 is powerful Audio processing unit.

  Inputs:    - Type: 3 analog line inputs,

2 AES digital inputs

(shared connectors), and 1 RTA mic input - Connectors: Female XLRs for analog/AES digital audio formats and RTA mic input    - *Impedance*: > 30 kΩ, balanced line to line - *Outputs*:    - *Type*: 6 line outputs    - *Connectors*: Male XLR    - *Impedance*: 120 Ω, balanced line to line - *Processing*:    - *A/D Converter*: 24-bit with dbx Type IV Conversion System    - *D/A Converter*: 24-bit    - *Internal Processing Wordlength*: 32-bit floating point - *Performance*:    - *Dynamic Range*: 114 dB A-weighted; 110 dB unweighted    - *THD+Noise*: 0.0025% typical at +4 dBu, 1 kHz, 0 dB input gain    - *Frequency Response*: 20 Hz – 20 kHz, +0 /- 0.5 dB - *Other Features*:    - *AutoEQ*: Advanced automatic equalization algorithm    - *AFS*: Enhanced feedback elimination algorithm    - *Mobile Control*: Control the device from your mobile device using the control app Please note that these specs might not be exact for the DriveRack 260, but they should give you a general idea of what to expect from a dbx DriveRack series device ¹.
